Pre-insulated mechanical terminal lug, is used for termination of power cables started from 185 sqm to 400 sqm, the voltage up to 1KV.
The terminal lug ICL-2-185-400 is applied with the following cables:
· Low voltage power cable, overhead and underground.
· Solar photovoltaic bus cables in PV combiner boxes.
It’s commonly used to connect power cables to electrical equipment such as switches, circuit breakers, or transformers, joint wires together in electrical panels or distribution boxes.
Technical specification
Product code
Cable size, mm2
Lug palm size, mm
Size bolt, M/ hex size
No. of bolts
ICL-2-185-400
185-400
17
22/22
2
Components and Materials
Bolted Pre-Insulated Electrical Terminal Lug is under Research and Design RnD by Jera Line, who has direct factory in China with organized production process, the Mechanical shear head lug consists of the following main part:
.png)
