Insulation Piercing Fuse Holder FHp-450-2258

Insulation Piercing Fuse Holder FHp-450-2258 either called fuse holder junction connector, was developed to apply with electrical ABC cables at the voltages up to 6KV, or photovoltaic solar cable netw
Insulation Piercing Fuse Holder FHp-450-2258
Features
  • No more of stripping the cable’s insulation required
  • Universal cable application of LV ABC cable 16-50 mm2.
  • Universal cable application of PV cables 4-16 mm2, with double jacket’s insulation
  • Copper and alum cable applications.
  • Application of 22*58 mm fuse cassette up to 80A
  • Conforms to EMC, EN-50483-4 NF C 33 020, IP-67 criteria of testing procedures.
Contact Us
DESCRIPTION
TEST
REVIEW

Application

The ABC cable fuse holder  is an automatic switch that designed to prevents current from flowing in the event of rapid overload or abnormal pressure to protects the related electrical equipment. The PV cable fuse Holder work with cables of 4-50mm ² sizes during of installation of service line systems, street lightning, building, up to 6KV, small and large scale of solar power facilities.

Technical specification

Product name Cable Size (mm²) Fuse cassette size Shear head torque N*m
FHp-450 4-50 22*58 mm 10+-1.5

Components and materials

This insulation piercing fuse holder body is made of UV resistant material, which can be applied in various weather conditions for a long time usage. The fuse hold passed a series test according to EN50483-4, NFC33020 .

Dimensions

Test

Example of a mini-switch 10A functionning.
