The ZOP-P21 Insulation Piercing Connector (IPC), produced by Jera Line, is specifically designed for low-voltage (LV) applications involving bare or insulated aluminum cables. This innovative connector ensures safe, efficient, and reliable connections in various electrical distribution systems.
Key applications:
● Overhead Electrical Distribution
● Tap-Off Connections: Perfect for creating branch connections from a main conductor to secondary or service lines without stripping insulation.
● Industrial and Residential Projects: Utilized in industrial installations and residential complexes where durability and safety are paramount.
Technical
specification
Product code
Cable size, mm2
Main
Tap
ZOP-P21
10-25
2.5-35
Components and materials
The ZOP-P21 Aluminum cable Insulation Piercing Connector is engineered and manufacturered by Jera Line, a direct factorylocation in China who can provide Extended warranty,the piercing connector consissts of the following main part:
Components
Materials
Body cover
UV resistance polymer
Metal part
Aluminum
Dimensions
Test
Insulated bare Cable Piercing Clamp ZOP-P21 designed and produced by Jera Line, has undergone rigorous testing in Jera’s in-house laboratory. These tests ensure product performance, reliability, and compliance with international standards.
The standard is EN-50483:4, the European standard for connectors used in low-voltage overhead distribution systems.
The testing scope includes:
● Visual examination
● Dimensional and material verification
● Test for permanent marking
● Connector bolt tightening test
● Shear head function test
● Electrical ageing test
Jera Line offers a factory routine test report upon request. This report provides detailed results of the performed tests, ensuring that the ZOP-P21 clamp meets all quality and compliance standards. It is part of Jera Line’s commitment to providing thoroughly tested and high-quality products.
