Insulated Cable to bare cable Piercing Connector ZOP-9.21 (L) is specialized for connecting insulated aluminum cables to bare aluminum conductors. The connector is equipped with springs made of steel, to make the installation easier. The design enables hot line installation without peeling insulation of the conductor.
Technical
specification
Product code
Cable size, mm2
Torque, N*m
Main
Tap
ZOP-9.21(L)
16-120
16-95
20+-2
Components and materials
Insulation piercing Bare Connector ZOP-9.21(L), is manufacturered and Research
and Design RnD by Jera Line, a direct factorylocation in Chinawho can provide Extended warranty,the piercing connector consissts of the following main part:
Components
Materials
Body cover
UV resistance polymer
PG clamp perforated with teeth
Aluminum
Bolts, washers
Stainless steel
Spring
Steel
Dimensions
Test
Insulated bare Cable Tap Connector ZOP-9.21 (L) has undergone testing in Jera’s factory laboratory in accordance with the EN-50483:4 standard. The testing scope includes:
lVisual examination
lDimensional and material verification
lTest for permanent marking
lConnector bolt tightening test
lShear head function test
lElectrical ageing test
Additionally, Jera Line can provide a factory routine test report upon request, demonstrating compliance with standards and thorough quality assurance.
