Mechanical Shearhead Electrical Lug CLBIT-2-25-150, also called mechanical bolt lug, is a metal device used for connection cables to electrical appliances under voltage 1KV. It’s suitable for both aluminum and copper electrical cable during power line constructions.
Main Applications:
● Electrical Transmission and Distribution Lines: Secures electrical conductors to the system.
● Substation Equipment: Connects cables or busbars to equipment like transformers, circuit breakers, or switchgear.
● Grounding Systems: Connects ground wires to grounding rods or other components.
Technical specification
Product code
Cable size, mm2
Size of Bolt, M/hex size
Bolt number
Application cable
CLBIT-2-25-150
25-150
16/17
2
Copper/Aluminum
Components and Materials
Mechanical terminal Lug, CLBIT-2-25-150 is produced by a direct factory location in China -- Jera Line, and it is also under Research and Design RnD by Jera Line, Shear-off-head bolts lugs and electrical cables jointing process does not require the compression tool with exact size. All required tension force is achieved by shearing off the head of bolt by hex key, which tighten the bolt.
The mechanical lugconsists of the following main part:
