1. No Need for Cable Insulation Removal:
Unlike traditional fuse holders, the FHP 450 allows for the insertion of the cable into the fuse holder without stripping the insulation. This not only speeds up the installation process but also prevents damage to the cable’s inner conductors.
2. Waterproof Design:
The FHP 450 is IP 67 Waterproof , designed with a robust waterproof casing that protects the fuse and cable connections from rain, snow, and moisture. It ensures safe and reliable operation, even in harsh outdoor conditions.
3. High Voltage Rating:
The FHP 450 is rated for use with cables up to a certain voltage (typically 6KV), making it suitable for a wide range of low voltage applications.
4. Durable Materials:
The fuse holder is made from high-quality, UV-resistant materials to withstand long-term outdoor exposure and extreme temperatures.
Meets or exceeds international safety standards, such as EN-50485, NFE-33020, ensuring your electrical systems are protected and comply with regulations.
6. Bemital usage: Suitable for both AL (aluminum) and CU (copper) cables.
Installation Steps for the FHP 450 Outdoor Waterproof Cable Fuse Holder
Follow these simple steps to install the FHP 450 Outdoor Waterproof Cable Fuse Holder:
● De-energize the Circuit: Before beginning the installation, always ensure that the system is de-energized to avoid the risk of electrical shock.
● Personal Protective Equipment (PPE): Wear the necessary PPE, such as gloves and safety glasses, to protect yourself from potential electrical hazards.
● Inspect the Cable: Inspect the cable to ensure that it is in good condition.
● Clean the Cable: Clean the cable at the connection point to ensure that there is no dirt, dust, or debris that could interfere with the connection.
● Cable Size: Make sure that the cable size is compatible with the FHP 450 fuse holder 4-50mm2.
● No Insulation Removal Required: The FHP 450 does not require you to strip the insulation from the cable. Simply insert the cable into the fuse holder, ensuring that it is aligned properly and the conductor is in full contact with the connection point inside the holder.
● Secure the Cable: Once the cable is inserted, make sure it fits snugly within the fuse holder. The internal contacts will pierce through the outer insulation and make a secure electrical connection with the conductor.
● Install the Fuse: The FHP 450 fuse holder is designed to accommodate a standard fuse link 22*58. Insert the appropriate fuse into the fuse holder slot.
● Ensure Proper Fit: Make sure the fuse is properly seated and that the fuse holder is securely closed.
● Tighten Securely: Using a wrench or appropriate tool, tighten the connector screws.
● Visual Inspection: After installation, visually inspect the fuse holder to ensure that the cable is correctly inserted and that there are no loose components.
● Check for Proper Alignment: Ensure that the cable is aligned correctly and that the insulation has not been damaged during installation.
● Restore Power: Once installation is complete, restore power to the system and test the operation of the fuse holder.
● Monitor for Any Issues: After installation, monitor the system for any signs of overheating, short circuits, or other issues. The FHP 450 is designed to provide long-lasting protection, but it's important to ensure that the installation is free from faults.
The FHP 450 Outdoor Waterproof Cable Fuse Holder is an excellent choice for both residential and industrial power distribution systems. Its key advantages include:
● Time-saving Installation: No need to strip insulation from the cable, reducing installation time and preventing potential damage to the cable.
● Superior Durability: Built to withstand harsh outdoor conditions, from high temperatures to moisture exposure.
● Enhanced Safety: Designed to minimize electrical hazards and ensure that the system remains protected from overloads and short circuits.
● Cost-effective Solution: Offering long-term reliability without requiring frequent maintenance or costly repairs.
The FHP 450 Outdoor overvoltage protection Fuse Holder by Jera Line is an innovative and reliable solution for connecting cables in outdoor environments. The FHP 450 saves you time and effort while ensuring a secure and protected connection.
For more information on the FHP 450 or to inquire about other electrical solutions, contact Jera Line today! We are committed to providing high-quality products that ensure the safety, reliability, and efficiency of your electrical systems.
