Shear Head Bolt Mechanical Connector, CCBVzT-4-120-300

Shear Head Bolt Electrical cable Connector, 4 torque bolts, tin plated Aluminum Alloy material, 70-240 mm2 Aluminum and copper cable application, 0.4- 36KV

Features

Fast and convenient installation process with a hex key
High mechanical strength with steady shear head torque
Wide range application for electrical cable from 120 to 300mm2
Material: Tin covered Aluminum Alloy, both aluminum and copper cables suitable
Direct Factory location in China

DESCRIPTION

TEST

REVIEW

Application

Shear Head Bolt Cable Mechanical Connector CCBVzT-4-120-300, It can be used in 0.4-36KV aluminum or copper cables distribution systems.

· Power distribution systems: To connect aluminum or copper power cables in utility or industrial applications.

· Grounding Systems: It can be employed to connect ground wires to grounding rods or other grounding components.

Technical specification

Product code	Cable size, mm2	Torque, N*m	Bolt number	Application cable
CCBVzT-4-120-300	120-300	40/42/44	4	Copper/Aluminum

Components and materials

Shear Bolt Electrical Mechanical Connector CCBVzT-4-120-300 is produced by a direct factory location in China -- Jera Line, and it is also under Research and Design RnD by Jera Line, the MV mechanical connector consists of the following main part:

Components	Materials
Body	Aluminum alloy, tin covered
Compensating size ring	UV resistant polymer

Dimensions

Test

Shear Head Bolt Mechanical Terminal Connector CCBVzT-4-120-300 has passed routine test by Jera Line own factory laboratory, if the test report required, Jera Line can provide factory test report which according to standard IEC-61238-3.

The testing scopes are as following:

· Visual inspection test and dimensional and material verification test

· Mechanical tension test according to standard IEC 61238-1-3

· Shear head functions test according to standard IEC 61238-1-3
