Aluminum Torque Cable Connector, CCBVzT-36-4-70-240

Aluminum Torque Cable Terminal connector, 4 torque bolts, 0.4- 36KV usage, tin plated Aluminum Alloy material, 70-240 mm2 Aluminum and copper cable application

Features

High mechanical strength with steady shear head torque
Wide range application for electrical cable from 70 to 240mm2
Rapid installation process with a hex key
Tin covered Aluminum Alloy material, suitable for both aluminum and copper cables
Manufactured according to standard IEC-61238-1-3
Direct Factory

DESCRIPTION

TEST

REVIEW

Application

Aluminum Torque Wire Connector CCBVzT-36-4-70-240, It can be used in 0.4-36KV aluminum or copper cables distribution systems.

· Power distribution systems: To connect aluminum or copper power cables in utility or industrial applications.

· Grounding Systems: It can be employed to connect ground wires to grounding rods or other grounding components.

Technical specification

Product code	Cable size, mm2	Torque, N*m	Bolt number	Application cable
CCBVzT-36-4-70-240	70-240	36/38/40	4	Copper/Aluminum

Components and materials

Aluminum Torque Electrical Connector CCBVzT-36-4-70-240 is produced by a direct factory location in China -- Jera Line, and it is also under Research and Design RnD by Jera Line, the MV mechanical connector consists of the following main part:

Components	Materials
Body	Aluminum alloy, tin covered
Compensating size ring	UV resistant polymer

Dimensions

Test

Aluminum Torque Conductor Connector CCBVzT-36-4-70-240 has passed routine test by Jera Line own factory laboratory, if the test report required, Jera Line can provide factory test report which according to standard IEC-61238-3.

The testing scopes are as following:

· Visual inspection test and dimensional and material verification test

· Mechanical tension test according to standard IEC 61238-1-3

· Shear head functions test according to standard IEC 61238-1-3
